Paradyne CSU - Manual (Page 240)

7. Operation and Maintenance
7-58 September 2002 9128-A2-GB20-80
Total Rx Frames/
Rx Octets Total number of data frames and octets ( 8-bit bytes) received for
the selected DLCI on the frame relay link.
T Within CIR T The number of frames and octets received on the selected
DLCI of the frame relay link that were within the committed
information rate.
T Between CIR&EIR T The number of frames and octets received on the selected
DLCI of the frame relay link that were between the committed
information rate and excess information rate.
T Above EIR T The number of frames and octets received on the selected
DLCI of the frame relay link that were above the excess
information rate.
T With DE Set T The number of frames and octets received on the selected
DLCI of the frame relay link with the discard eligible bit set.
T With BECN Set T The number of frames and octets received on the selected
DLCI of the frame relay link with backward explicit congestion
notifications.
BECNs are sent to notify users of data traffic congestion in
the opposite direction of the frame carrying the BECN
indicator.
T With FECN Set T The number of frames and octets received on the selected
DLCI of the frame relay link with forward explicit congestion
notifications.
The network sends FECNs to notify users of data traffic
congestion in the same direction of the frame carrying the
FECN indicator.
Table 7-18. DLCI Performance Statistics (2 of 2)
Statistic What It Indicates
* Only appears for the network interface.
