FrameSaver SLV 9126 LEDs and Control Leads
The FrameSaver SLV 9126-A1 unit’s faceplate includes LEDs (light-emitting
diodes) that provide status on the FrameSaver unit, its network interface, DSX-1
interface, and DTE interface.
The FrameSaver SLV 9126-A2-201’s faceplate includes LEDs that provide status
on the FrameSaver unit, its network interface, DSX-1 interface, and DTE interface.
The FrameSaver SLV 9126-II’s and FrameSaver SLV 9126-II Router’s faceplates
include LEDs that provide status on the FrameSaver unit, its backup mode, its
network interface, DSX-1 interface, and DTE interface. The PORT LED refers to
the user data port on the CSU/DSU, and the Ethernet port on the router.
2-OK OK ALM TST BKP SIG OOF ALM SIG OOF ALM 1-OK
9126
NETWORK DSX PORT
FrameSaver TM SLV FrameSaver ® SLV
00-16182-01
OK OK ALM TST SIG OOF ALM SIG OOF ALM
9126
NETWORK DSX PORT
FrameSaver TM SLV FrameSaver ® SLV
02-17142a
OK OK ALM TST BKP SIG OOF ALM SIG OOF ALM
9126
NETWORK DSX PORT
FrameSaver TM SLV FrameSaver ® SLV
02-17142
