2. User Interface and Basic Operation
9128-A2-GB20-80 September 2002 2-5
Screen Work Areas
There are two user work areas:
T Screen area – Where you input information into fields.
T Function keys area – Where you perform specific screen functions.
Below is a sample configuration screen.
Screen Area
Function Keys Area
Menu Path
Device Name
Message Area
main /config/system/slv 9128-IISLV
Device Name: Node A 08/23/2002 10:59
SERVICE LEVEL VERIFICATION SYSTEM OPTIONS
SLV Sample Interval (secs): 60
SLV Synchronization Role: Tributary
SLV Type: Standard
SLV Delivery Ratio: Disable
DLCI Down on SLV Timeout: Enable
SLV Timeout Error Event Threshold: 3
SLV Timeout Clearing Event Threshold: 1
SLV Round Trip Latency Error Threshold (ms): 10000
SLV Latency Clearing Event Threshold: 2
SLV Packet Size (bytes): 64
-------------------------------------------------------------------------------
Ctrl-a to access these functions, ESC for previous menu MainMenu Exit
Save
Date and Time
Model Number
Screen Format Description
Menu Path Menu selections made to reach the current screen.
Device Name Customer-assigned identification of the FrameSaver unit.
9126, 9126-SLV, 9126-IISLV,
9126-IIR, 9126-IIRSLV,
9128-II, or 9128-IISLV FrameSaver unit’s model number.
Screen Area Selection, display, and input fields for monitoring and
maintaining the FrameSaver unit.
Function Keys Area Specific functions that can be performed by pressing a
specified key, then pressing Enter.
Message Area System-related information and valid settings for input
fields are in the lower left corner.
System and Test Status messages are in the lower right
corner.
