7. Operation and Maintenance
7-22 September 2002 9128-A2-GB20-80
ISDN Link Profile Disabled
ISDN Link Name
An ISDN backup call could not be made because the
ISDN link profile specified Link Name is disabled
(
Main Menu
→
Configuration
→
ISDN
→
Link Profiles) .
ISDN Link Profile Invalid,
ISDN Link Name
No phone numbers have been specified in the ISDN
link profile (specified by
ISDN Link Name ).
ISDN Network Failed (Active/ Idle) An ISDN network failure was detected when:
T Active – Backup call was in progress.
T Idle – DBM was in Idle mode.
LatExceed IP_ Address,
COS x, DLCI nnnn
1
An IP SLV Latency Threshold has been exceeded for
the specified COS of the path.
IP_Address is the IP
address of the path endpoint, COS x is the Class of
Service ID associated with the path, and nnnn is the
DLCI which contains the path.
Link Down Administratively, frame
relay link
2
The specified frame relay link has been disabled by
the unit due to LMI Behavior conditions or LMI
Protocol on another link is in a failed state.
Link Profile Disabled,
ISDN Link Name
An ISDN backup call could not be made because the
specified link profile was disabled.
LLB Active, [Interface] A network Line Loopback (LLB) is active on the
specified interface.
LMI Discovery in Progress, frame
relay link 2
Local Management Interface protocol discovery is in
progress to determine which protocol will be used on
the specified frame relay link.
LMI Down, frame relay link 2
The Local Management Interface(s) has been
declared down for the specified frame relay link.
T For an individual ISDN link, the message appears
when LMI has been declared down on the link.
T For a multilink aggregate link, the message
appears when LMI has been declared down on all
constituent links of the frame relay multilink.
LOS at DSX-1 A Loss of Signal (LOS) condition is detected on the
DSX-1 interface. Clears when the ratio of ones to
zeros received is greater than or equal to 12.5%.
Possible reasons include:
T DSX-1 cable problem.
T No signal being transmitted from the DTE.
Table 7-8. Health and Status Messages (3 of 7)
Message What It Indicates
1
nnnn indicates a DLCI number of 16 through 1007.
2
frame relay link is one of the following:
– Net1-FR1. The frame relay link specified for the network interface, Network 1.
– Port-
n . The frame relay link associated with the user data port.
– ISDN Link Name on a non-network ISDN DBM interface.
3
Does not apply to a TS Management Link DLCI.
