114
Chapter
2
File
Menu
700
File – Import – Digitizer – PC Card (When VIVID 700 is Selected)
Parameters for [File-Import-Digitizer-PC Card-Load] Dialog Box
Reduction Rate Selects the reduction rate to be applied when importing the data. You can select any of the following:
“1/1”, “1/4”, “1/9”, “1/16”, or “No polygon”.
Fill Holes Selects whether the programs fill in holes when importing the data. If the setting is “On”, the pro-
gram will automatically generate points to fill in holes left by missing data.
Remove Selects which the data the program excludes when carrying out the import. Select from an of the
following: “None”, “Boundary (B.)”, “5deg. & B.”, “10deg. & B.”, “15deg. & B.”,
None: Removal is not carried out when importing the data.
Boundary(B.): The program removes boundary points.
5deg. & B.,10deg. & B., 15deg. & B., 20deg. & B.:
The program removes boundary points, and also removes polygons within the
specified angular range (5°, 10 °, 15° or 20 °) to the view vector.
Filter None: The program does not perform filtering when importing the data.
Noise Filter (N.F.): When importing the data, the points that appear to be noise will be corrected
according to other data.
n Deleting the Selected File ([Delete] button)
The [Delete] button is used to delete the selected file from the memory card.
Operating Procedure
Before starting the following procedure, make sure that the [File-Import-Digitizer-PC Card] dialog box is
displayed.
1 From the file list, select the file you
want to delete.
2 Click the [Delete] button.
A message dialog box will appear.
3 Click the [Delete] button.
The file will be deleted.
