SMC Networks TIGERSWITCH 10/100 - Manual (Page 107)

C
ONFIGURING
P
RIVATE
VLAN
S
2-75
CLI – This example shows the switch configured with primary
VLAN 5 and secondary VLAN 6. Port 3 has been configured as a
promiscuous port and mapped to VLAN 5, while ports 4 and 5
have been configured as a host ports and associated with VLAN 6.
This means that traffic for port 4 and 5 can only pass through port
3.
]
Configuring Private VLAN Interfaces
Use the Private VLAN Port Configuration and Private VLAN Trunk
Configuration menus to set the private VLAN interface type, and
associate the interfaces with a private VLAN.
Command Attributes
• Port/Trunk – The switch interface.
• PVLAN Port Type – Sets the private VLAN port types.
- Normal – The port is not configured into a private VLAN.
- Host – The port is a community port and can only
communicate with other ports in its own community VLAN,
and with the designated promiscuous port(s).
- Promiscuous – A promiscuous port can communicate with
all interfaces within a private VLAN.
Console#show vlan private-vlan 3-139
Primary Secondary Type Interfaces
-------- ----------- ---------- ------------------
5 primary Eth1/ 3
5 6 community Eth1/ 4 Eth1/ 5
Console#
