C

ONFIGURING

THE

S

WITCH

3-14

CLI – Specify the hostname, location and contact information.

Displaying Switch Hardware/Software Versions

Use the Switch Information page to display hardware/firmware version
numbers for the main board and management software, as well as the
power status of the system.

Field Attributes

Main Board

Serial Number – The serial number of the switch.

Number of Ports – Number of built-in ports.

Hardware Version – Hardware version of the main board.

Console(config)#hostname R&D 5

4-33

Console(config)#snmp-server location WC 9

4-150

Console(config)#snmp-server contact Bill

4-150

Console(config)#exit
Console#show system

4-80

System description: SMC8748M/SMC8724M
System OID string: 1.3.6.1.4.1.202.20.42
System information
System Up time: 0 days, 19 hours, 6 minutes, and 1.43
seconds
System Name: R&D 5
System Location: WC 9
System Contact: Bill
MAC address (unit1): 00-30-F1-DF-9C-A0
Web server: enabled
Web server port: 80
Web secure server: enabled
Web secure server port: 443
Telnet server: enable
Telnet server port: 23
Jumbo Frame: Enabled
POST result
DUMMY Test 1 ................. PASS
UART Loopback Test ........... PASS
DRAM Test .................... PASS
Timer Test ................... PASS
PCI Device 1 Test ............ PASS
I2C Bus Initialization ....... PASS
Switch Int Loopback Test ..... PASS
Crossbar Int Loopback Test ... PASS
Fan Speed Test ............... PASS

Done All Pass.
Console#
