SMC Networks SMC TigerStack 1000 SMC8748M - Manual (Page 462)

C
OMMAND
L
INE
I
NTERFACE
4-190
Example
The following shows mirroring configured from port 6 to port 11.
Rate Limit Commands
This function allows the network manager to control the maximum rate
for traffic transmitted or received on an interface. Rate limiting is
configured on interfaces at the edge of a network to limit traffic into or out
of the network. Traffic that falls within the rate limit is transmitted, while
packets that exceed the acceptable amount of traffic are dropped.
Rate limiting can be applied to individual ports or trunks. When an
interface is configured with this feature, the traffic rate will be monitored
by the hardware to verify conformity. Non-conforming traffic is dropped,
conforming traffic is forwarded without any changes.
Console(config)#interface ethernet 1/11
Console(config-if)#port monitor ethernet 1/6
Console(config-if)#end
Console#show port monitor
Port Mirroring
-------------------------------------
Destination port(listen port):Eth1/1
Source port(monitored port) :Eth1/6
Mode :RX/TX
Console#
Table 4-48 Rate Limit Commands
Command Function Mode Page
rate-limit Configures the maximum input or output
rate for a port IC 4-191
