P

ORT

C

ONFIGURATION

3-117

Web – Click Port, LACP, Port Counters Information. Select a member
port to display the corresponding information.

Figure 3-54 LACP - Port Counters Information

Marker Received

Number of valid Marker PDUs received by this channel
group.

LACPDUs Unknown
Pkts

Number of frames received that either (1) Carry the Slow
Protocols Ethernet Type value, but contain an unknown
PDU, or (2) are addressed to the Slow Protocols group
MAC Address, but do not carry the Slow Protocols
Ethernet Type.

LACPDUs Illegal Pkts Number of frames that carry the Slow Protocols Ethernet

Type value, but contain a badly formed PDU or an illegal
value of Protocol Subtype.

Table 3-7 LACP Port Counters (Continued)

Field

Description
