C
ONFIGURING THE
S
WITCH
3-102
CLI – This examples assigns an IP and MAC ingress ACL to port 1, and
an IP ingress ACL to port 2.
Port Configuration
Displaying Connection Status
You can use the Port Information or Trunk Information pages to display
the current connection status, including link state, speed/duplex mode,
flow control, and auto-negotiation.
Field Attributes (Web)
• Name – Interface label.
• Type – Indicates the port type. (1000BASE-T or SFP)
• Admin Status – Shows if the interface is enabled or disabled.
• Oper Status – Indicates if the link is Up or Down.
• Speed Duplex Status – Shows the current speed and duplex mode.
(Auto, or fixed choice)
• Flow Control Status – Indicates the type of flow control currently in
use. (IEEE 802.3x, Back-Pressure or None)
• Autonegotiation – Shows if auto-negotiation is enabled or disabled.
• Media Type 3 – Shows the forced/preferred port type to use for
combination ports 21-24/45-48. (Copper-Forced,
Copper-Preferred-Auto, SFP-Forced, SFP-Preferred-Auto)
• Trunk Member 3 – Shows if port is a trunk member.
• Creation 4 – Shows if a trunk is manually configured or dynamically set
via LACP.
Console(config)#interface ethernet 1/1 4-174
Console(config-if)#ip access-group david in 4-128
Console(config-if)#mac access-group jerry in 4-141
Console(config-if)#exit
Console(config)#interface ethernet 1/2
Console(config-if)#ip access-group david in
Console(config-if)#
3. Port Information only.
4. Trunk Information only.
