C

LASS

OF

S

ERVICE

C

ONFIGURATION

3-199

Note: Mapping specific values for IP Port Priority is implemented as an

interface configuration command, but any changes will apply to
the all interfaces on the switch.

Mapping CoS Values to ACLs

Use the ACL CoS Mapping page to set the output queue for packets
matching an ACL rule as shown in the following table. Note that the
specified CoS value is only used to map the matching packet to an output
queue; it is not written to the packet itself. For information on mapping
the CoS values to output queues, see page 3-188.

Command Usage

You must configure an ACL mask before you can map CoS values to the
rule.

Command Attributes

Port – Port identifier.

Name* – Name of ACL.

Type – Type of ACL (IP or MAC).

CoS Priority – CoS value used for packets matching an IP ACL rule.
(Range: 0-7)

* For information on configuring ACLs, see page 3-87.

Table 3-15 Egress Queue Priority Mapping

Priority

0

1

2

3

4

5

6

7

Queue

1

2

0

3

4

5

6

7
