C
ONFIGURING THE
S
WITCH
3-148
Web – Click Spanning Tree, STA, Configuration. Modify the required
attributes, and click Apply.
Figure 3-66 STA Configuration
CLI – This example enables Spanning Tree Algorithm, sets the mode to
MST, and then configures the STA and MSTP parameters.
Console(config)#spanning-tree 4-212
Console(config)#spanning-tree mode mst 4-213
Console(config)#spanning-tree priority 4096 4-217
Console(config)#spanning-tree hello-time 5 4-215
Console(config)#spanning-tree max-age 20 4-216
Console(config)#spanning-tree forward-time 20 4-214
Console(config)#spanning-tree pathcost method long 4-217
Console(config)#spanning-tree transmission-limit 4 4-218
Console(config)#spanning-tree mst configuration 4-219
Console(config-mstp)#revision 1 4-222
Console(config-mstp)#name R&D 4-222
Console(config-mstp)#max-hops 30 4-223
Console(config-mstp)#
