Programming Issues
1
Table 1-8. MCECC Internal Register Memory Map
MCECC Base Address = $FFF43000 (1st); $FFF43100 (2nd)
Register
Offset
Register
Name
Register Bit Names
D31 D30 D29 D28 D27 D26 D25 D24
$00 CHIP ID CID7 CID5 CID5 CID4 CID3 CID2 CID1 CID0
$04 CHIP
REVISION
REV7 REV6 REV5 REV4 REV3 REV2 REV1 REV0
$08 MEMORY
CONFIG
0 0 FSTR
D
1 0 MSIZ2 MSIZ1 MSIZ0
$0C DUMMY 0 0 0 0 0 0 0 0 0
$10 DUMMY 1 0 0 0 0 0 0 0 0
$14 BASE
ADDRESS
BAD31 BAD30 BAD2
9
BAD2
8
BAD27 BAD26 BAD25 BAD24
$18 DRAM
CONTROL
BAD23 BAD22 RWB5 SWAI
T
RWB3 NCEIE
N
NCEB
EN
RAMEN
$1C BCLK
FREQUENCY
BCK7 BCK6 BCK5 BCK4 BCK3 BCK2 BCK1 BCK0
$20 DATA
CONTROL
0 0 DERC ZFILL RWCKB 0 0 0
$24 SCRUB
CONTROL
RACO
DE
RADA
TA
HITDI
S
SCRB SCRBEN 0 SBEIE
N
IDIS
$28 SCRUB
PERIOD
SBPD1
5
SBPD1
4
SBPD1
3
SBPD
12
SBPD11 SBPD1
0
SBPD9 SBPD8
$2C SCRUB
PERIOD
SBPD7 SBPD6 SBPD5 SBPD
4
SBPD3 SBPD2 SBPD1 SBPD0
$30 CHIP
PRESCALE
CPS7 CPS6 CPS5 CPS4 CPS3 CPS2 CPS1 CPS0
$34 SCRUB TIME
ON/OFF
SRDIS 0 STON
2
STON
1
STON0 STOFF
2
STOFF
1
STOFF0
$38 SCRUB
PRESCALE
0 0 SPS21 SPS20 SPS19 SPS18 SPS17 SPS16
$3C SCRUB
PRESCALE
SPS15 SPS14 SPS13 SPS12 SPS11 SPS10 SPS9 SPS8
$40 SCRUB
PRESCALE
SPS7 SPS6 SPS5 SPS4 SPS3 SPS2 SPS1 SPS0
$44 SCRUB
TIMER
ST15 ST14 ST3 ST12 ST11 ST10 ST9 ST8
