3-38 Computer Group Literature Center Web Site
PCCchip2
3
SCSI Interrupt Control Register
IL2-IL0 Interrupt Request Level. These three bits select the
interrupt level for the SCSI Processor. Level 0 does not
generate an interrupt.
IEN Interrupt Enable. When this bit is high, the interrupt is
enabled. The interrupt is disabled when this bit is low.
IRQ Interrupt Status. This status bit reflects the state of the
IRQ* pin of the SCSI Processor (qualified by the IEN bit).
When this bit is high, a SCSI processor interrupt is being
generated at the level programmed in IL2-IL0 (if
nonzero). This status bit does not need to be cleared,
because it is not edge-sensitive.
ADR/SIZ $FFF4202F (8 bits)
BIT 7 6 5 4 3 2 1 0
NAME IRQ IEN IL2 IL1 IL0
OPER R/W R/W R R/W R/W R/W R/W R/W
RESET 0 PL 0 PL 0 PL 0 PL 0 PL 0 PL 0 PL 0 PL
