http://www.motorola.com/computer/literature IN-7
I
N
D
E
X
local bus interrupter registers
I/O Control register 1 2-96
I/O Control register 2 2-97
I/O Control register 3 2-97
Interrupt Level register 4 (bits 0-7) 2-95
Miscellaneous Control register 2-98
Status register (bits 16-23) 2-78
Status register (bits 24-31) 2-77
Vector Base register 2-95
local bus master 2-9
VMEbus and 2-10
local bus slave (VMEbus master) registers
Address Translation Address Register 4
2-42
Address Translation Select Register 4
2-42
Attribute Register 1 2-46
Attribute Register 2 2-45
Attribute Register 3 2-44
Attribute Register 4 2-43
Ending Address Register 1 2-39
Ending Address Register 2 2-40
Ending Address Register 3 2-41
Ending Address Register 4 2-41
Starting Address Register 1 2-40
Starting Address Register 2 2-40
Starting Address Register 3 2-41
Starting Address Register 4 2-42
local bus slave, composition of 2-4
local bus timer
VMEchip2 ASIC 2-18
local control and status segisters (LCSRs),
VMEbus 2-7
local I/O devices memory map 1-22
local reset driver, VMEbus 2-18
local reset, VMEbus 2-18
local SCSI ID 1-45
local-bus-to-VMEbus
Enable Control register 2-49
I/O Control register 2-50
interface 1-18
interface, VMEchip2 2-4
map decoders, programming 2-37
requester 2-7
requester register, programming 2-51
location monitor
interrupters, VMEbus 2-19
status register (VMEchip2 ASIC) 2-101
location monitors LM0-LM3 (VMEchip2
ASIC) 2-100
LVFAIR bit (VMEchip2 ASIC) 2-8
M
M48T58 BBRAM, TOD Clock memory map
1-42
manual strobe control 3-45
map decoders 2-37
GCSR 1-46
SDRAM 1-11
VMEbus interface 1-46
VMEchip2 ASIC 2-4 , 2-6 , 2-9
master interrupt enable (MIEN) bit 2-74 ,
2-96
master interrupt enable (PCCchip2 ASIC)
3-15
MC68040
bus master support for 82596C 3-4
MPU 1-7
MC68060
MPU 1-7
MC680x0
indivisible RMW memory accesses 1-52
MOVE16 access 3-10
normal access 3-10
MCECC chip Memory Controller ASIC 1-3
MCECC internal register memory map 1-34
MCECC sector
arbitration process 4-9
Base Address register 4-15
BCLK Frequency register 4-16
chip defaults 4-9
Chip Prescaler counter 4-21
Data Control register 4-17
Defaults register 1 4-30
