2-88 Computer Group Literature Center Web Site
VMEchip2
2
Interrupt Level Register 1 (bits 16-23)
This register is used to define the level of the SYSFAIL interrupt and the
master write post bus error interrupt.
WPE LEVEL These bits define the level of the master write post bus
error interrupt.
SYSF LEVEL These bits define the level of the SYSFAIL interrupt.
Interrupt Level Register 1 (bits 8-15)
This register is used to define the level of the VMEbus IRQ1
edge-sensitive interrupt and the level of the external interrupt.
IRQ1E LEVEL
These bits define the level of the VMEbus IRQ1
edge-sensitive interrupt.
PE LEVEL Not used on MVME1x7P.
ADR/SIZ $FFF40078 (8 bits [6 used] of 32)
BIT 23 22 21 20 19 18 17 16
NAME SYSF LEVEL WPE LEVEL
OPER R/W R/W
RESET 0 PSL 0 PSL
ADR/SIZ $FFF40078 (8 bits [6 used] of 32)
BIT 15 14 13 12 11 10 9 8
NAME PE LEVEL IRQ1E LEVEL
OPER R/W R/W
RESET 0 PSL 0 PSL
