2-78 Computer Group Literature Center Web Site
VMEchip2
2
Local Bus Interrupter Status Register (bits 16-23)
This register is the local bus interrupter status register. When an interrupt
status bit is high, a local bus interrupt is being generated. When an interrupt
status bit is low, a local interrupt is not being generated. The interrupt
status bits are:
LM0 GCSR LM0 interrupt.
LM1 GCSR LM1 interrupt.
SIG0 GCSR SIG0 interrupt.
SIG1 GCSR SIG1 interrupt.
SIG2 GCSR SIG2 interrupt.
SIG3 GCSR SIG3 interrupt.
DMA DMAC interrupt.
VIA VMEbus interrupter acknowledge interrupt.
ADR/SIZ $FFF40068 (8 bits of 32)
BIT 23 22 21 20 19 18 17 16
NAME VIA DMA SIG3 SIG2 SIG1 SIG0 LM1 LM0
OPER R R R R R R R R
RESET 0 PSL 0 PSL 0 PSL 0 PSL 0 PSL 0 PSL 0 PSL 0 PSL
