Programming Model
http://www.motorola.com/computer/literature 4-31
4
The states of RSIZ2-0 after reset (power-up, soft, or local)
match those of the RSIZ2-0 bits from the reset serial bit
stream.
SELI1, SELI0
The SELI1, SELI0 control bits determine the base address
at which the control and status registers respond, as shown
below:
SELI1 and SELI0 are initialized by hardware after a
power-up, soft, or local reset. Their initialized state is
determined by board-level configuration resistors.
FSTRD The FSTRD control bit determines the speed at which
SDRAM reads occur. When it is 1, SDRAM reads happen
at full speed. When it is 0, SDRAM reads are slowed by
one clock, unless they are already slowed by NCEBEN
RSIZ2 RSIZ1 RSIZ0 DRAM Array Size
0 0 0 4MB
0 0 1 8MB
0 1 0 16MB
0 1 1 32MB
1 0 0 64MB
1 0 1 128MB
1 1 0 Reserved
1 1 1 Reserved
SELI1 SELI0 Register Base Address
0 1 $FFF43000
1 0 $FFF43100
