2-90 Computer Group Literature Center Web Site
VMEchip2
2
Interrupt Level Register 2 (bits 16-23)
This register is used to define the level of the GCSR SIG2 interrupt and the
GCSR SIG3 interrupt.
SIG2 LEVEL These bits define the level of the GCSR SIG2 interrupt.
SIG3 LEVEL These bits define the level of the GCSR SIG3 interrupt.
Interrupt Level Register 2 (bits 8-15)
This register is used to define the level of the GCSR SIG0 interrupt and the
GCSR SIG1 interrupt.
SIG0 LEVEL These bits define the level of the GCSR SIG0 interrupt.
SIG1 LEVEL These bits define the level of the GCSR SIG1 interrupt.
ADR/SIZ $FFF4007C (8 bits [6 used] of 32)
BIT 23 22 21 20 19 18 17 16
NAME SIG3 LEVEL SIG2 LEVEL
OPER R/W R/W
RESET 0 PSL 0 PSL
ADR/SIZ $FFF4007C (8 bits [6 used] of 32)
BIT 15 14 13 12 11 10 9 8
NAME SIG1 LEVEL SIG0 LEVEL
OPER R/W R/W
RESET 0 PSL 0 PSL
