3-48 Computer Group Literature Center Web Site
PCCchip2
3
Interrupt Priority Level Register
IPL2-IPL0 Interrupt Priority Level - These bits reflect the priority-
encoded interrupt request level. This level is a
combination of the PCCchip2 interrupt requests and the
interrupt requests driven onto the EIPL2-EIPL0 pins.
Note that when the C040 bit is cleared, external devices
can drive EIPL2-EIPL0 with their interrupt requests.
When C040 is set, the PCCchip2 drives EIPL2-EIPL0
with its interrupt requests. In this case (C040 set), IPL2-
IPL0 only reflect PCCchip2 interrupt requests. The IPL
bits are encoded as shown below:
ADR/SIZ $FFF4203E (8 bits)
BIT 15 14 13 12 11 10 9 8
NAME IPL2 IPL1 IPL0
OPER R R R R R R R R
RESET 0 0 0 0 0 X X X
IPL2 IPL1 IPL0 Priority Level Comments
0 0 0 0 No Interrupt
0 0 1 1 Lowest Level
0 1 0 2
0 1 1 3
1 0 0 4
1 0 1 5
1 1 0 6
1 1 1 7 Highest Level
