4-30 Computer Group Literature Center Web Site
MCECC Functions
4
Error Syndrome Register
S6-S0 Bits SYNDROME6-0 reflect the syndrome value at the last
logging of an error. The seven-bit code indicates the
position of the data error. When all the bits are 0, there is
no error. Note that if the logged error was non-
correctable, then these bits are meaningless (refer to the
Syndrome Decoding section).
Defaults Register 1
It is not recommended that non-test software write to this register.
RSIZ2-RSIZ0
Bits RSIZ2-RSIZ0 determine the size of the DRAM array
that is assumed by the MCECC. They control the size as
follows:
ADR/SIZ 1st $FFF43070/2nd $FFF43170 (16-bits)
BIT 31 30 29 28 27 26 25 24
NAME 0 S6 S5 S4 S3 S2 S1 S0
OPER R R R R R R R R
RESET 0 PLS 0 PLS 0 PLS 0 PLS 0 PLS 0 PLS 0 PLS 0 PLS
ADR/SIZ 1st $FFF43074/2nd $FFF43174 (8-bits)
BIT 31 30 29 28 27 26 25 24
NAME RWB7 RWB6 FSTRD SELI1 SELI0 RSIZ2 RSIZ1 RSIZ0
OPER R/W R/W R/W R/W R/W R/W R/W R/W
RESET 0 PL V PLS V PLS V PLS V PLS V PLS V PLS V PLS
