Programming Model
http://www.motorola.com/computer/literature 4-11
4
Table 4-3. MCECC Sector Internal Register Memory Map
MCECC Sector Base Address = $FFF43000 (1st board); $FFF43100 (2nd board)
Register Register Bit Names
Offset Name D31 D30 D29 D28 D27 D26 D25 D24
$00 CHIP ID CID7 CID6 CID5 CID4 CID3 CID2 CID1 CID0
$04 CHIP
REVISION REV7 REV6 REV5 REV47 REV3 REV2 REV1 REV0
$08 MEMORY
CONFIG 0 0 FSTRD 1 0 MSIZ2 MSIZ1 MSIZ0
$0C 0 0 0 0 0 0 0 0
$10 0 0 0 0 0 0 0 0
$14 BASE
ADDRESS BAD31 BAD30 BAD29 BAD28 BAD27 BAD26 BAD25 BAD24
$18 DRAM
CONTROL BAD23 BAD22 RWB5 RWB4 RWB3 NCEIEN NCEBEN RAMEN
$1C BCLK
FREQUENCY BCK7 BCK6 BCK5 BCK47 BCK3 BCK2 BCK1 BCK0
$20 DATA
CONTROL 0 0 DERC ZFILL RWCKB 0 0 0
$24 SCRUB
CONTROL 0 0 0 SCRB SCRBEN 0 SBEIEN RWB0
$28 SCRUB
PERIOD SBPD15 SBPD14 SBPD13 SBPD12 SBPD11 SBPD10 SBPD9 SBPD8
$2C SCRUB
PERIOD SBPD7 SBPD6 SBPD5 SBPD4 SBPD3 SBPD2 SBPD1 SBPD07
$30 CHIP
PRESCALE CPS7 CPS6 CPS5 CPS4 CPS3 CPS2 CPS1 CPS0
$34 SCRUB TIME
ON/OFF SRDIS 0 STON2 STON1 STON0 STOFF2 STOFF1 SRDIS
$38 SCRUB
PRESCALE 0 0 SPS21 SPS20 SPS19 SPS18 SPS17 SPS16
$3C SCRUB
PRESCALE SPS15 SPS14 SPS13 SPS12 SPS11 SPS10 SPS9 SPS85
