AN07-00180-3E
- 97 -
Field name Setting value Remarks
Motor rotation
direction
0: Clockwise 1:
Counterclockwise
-
Brake application 0: Brake released 1: Brake
applied
-
Motor rotation speed 0 to 65535 The motor rotation speed and A/D maximum
value are used for conversion of the speed to a
percentage of 0% to 100%.
A/D maximum value 0 to 65535
3. ID: 0x103
Field name Setting value Remarks
Temperature
measurement
command
0: Start 1: Stop -
4. ID: 0x201
Field name Setting value Remarks
Motor rotation
direction information
0: Clockwise 1:
Counterclockwise
-
Brake application
information
0: Brake released 1: Brake
applied
-
Motor rotation speed
information
0 to 65535 The motor rotation speed and A/D
maximum value are used for conversion of
the speed to a percentage of 0% to 100%. A/D maximum value
information
0 to 65535
5. ID: 0x202
Temperature measurement command byte 0
byte 1
byte 2
byte 3
byte 4
Reserved
Reserved
byte 5
byte 6
byte 7
Reserved
Reserved
Reserved
Reserved
Reserved
Motor rotation direction information byte 0
Brake application information
Motor rotation speed information
A/D maximum value information
byte 1
byte 2
byte 3
byte 4
Reserved
Reserved
byte 5
byte 6
byte 7
