AN07-00180-3E

- 25 -

1.1.3

Installing the integrated development environment SOFTUNE (bits pot dedicated

version)

Note

If SOFTUNE V6 of the product version has been installed, first uninstall it, and then install the bits

pot dedicated version.

Start installing the integrated development environment SOFTUNE. Extract the following file from the

¥softwares¥softune¥

REV600010-BV.zip

Double-click “Setup.exe” in the decompressed folder; the dialog shown in “Figure 1-10 SOFTUNE setup

confirmation” is displayed. Click the “OK” button.

Figure 1-10 SOFTUNE setup confirmation

The setup wizard shown in “Figure 1-11 Starting SOFTUNE setup” is displayed; click the “Next” button.

Figure 1-11 Starting SOFTUNE setup
