Table 3-1 Single-unit operation/Descriptions of the controls and mechanicals
No. Name Function Description
(1) Mode SW Control
Switches between RPG mode and RUN mode.
PRG: Write a program
RUN: Run the program
(2) Reset SW Control Rests the MCU when pressed.
(3) SW2 Control
Rotates/stops the motor in turn when pressed. The
motor rotates if it is stopped and stops if it is rotating
when this switch is pressed.
(4) SW3 Control
Brakes the (stops) motor if it is rotating when pressed.
The brake is applied while the switch is pressed.
Releasing the switch turns off the brake and the motor
starts rotating.
(5) SW5 Control
Selects the direction of the motor rotation.
Right side: The motor rotates clockwise.
Left side: The motor rotates counterclockwise.
(6) Temperature sensor Control
Changes the rotation speed according to information
from the temperature sensor.
When the temperature rises, the rotation speed
increases.
When the temperature falls, the rotation speed
decreases.
(7) LEDs (green) Mechanical
Indicate the status of whether the motor driver circuit is
ON/OFF.
(8) LEDs (red) Mechanical
Indicate the status of whether the hall elements are
ON/OFF.
(9) BLDC motor Mechanical
Operates according to rotation/stop by the SW2.
The brake, rotation direction, and rotation speed
respectively depend on the SW3, SW5, and temperature
sensor.
