Page 38

AN07-00180-3E

- 38 -

The message pane at the bottom of the window shows a message that tells no error was found as shown in

Figure 2-4 Completing the build

2.1.2

Writing the program into the microcontroller

Preparation

Set MODE on the board to “PRG” in advance.

Select “Start” → “All Programs” → “FUJITSU FLASH MCU Programmer” → “MB91F267NA” to

activate PC Writer.

To select a file to be written as shown in “Figure 2-5 Opening the file to write”, click the “Open” button.

Figure 2-5 Opening the file to write

Click this.
