AN07-00180-3E
- 63 -
3.2 CAN communication operation (CAN communication operation with the
bits pot white)
“Figure 3-2 CAN communication operation/Controls and mechanicals” shows the controls and
mechanicals, and “Table 3-2 CAN communication operation/Descriptions of the controls and
mechanicals” provides descriptions about them.
The bits pot white performs CAN communication, and on execution of a motor operation command, the
green and red LEDs and BLDC motor work. On execution of a temperature measurement command, the
temperature is returned from the temperature sensor.
Figure 3-2 CAN communication operation/Controls and mechanicals
④ CAN 送信 LED
⑤ CAN 受信 LED
(6) LEDs (green) (7) LEDs (red)
(2) Reset SW
(3) Temperature
sensor
(8) BLDC motor
(1) Mode SW
