1 Setting up the starter kit
Before using this starter kit, be sure to check the components listed in Table 1-1 are fully supplied.
Before connecting the bits pot red CAN-Motor board (referred to as the board hereafter), you need to
install software in your PC. You can download the software required for the starter kit from the following
web site.
bits pot URL：
Table 1-1 Component list
No.
Article
Qty.
Specifications
Remarks
1
bits pot red
CAN motor board
1
Microcontroller made by Fujitsu
FR Family FR60 Lite, MB91F267N
mounted
See Figure 1-1
2
USB cable
1
USB (A to miniB)
Accessory
3
BLDC Motor
1
Tsukasa Electronic TG-22D-F539,
12 V
Accessory
4
AC adapter
1
12 V, 1 A
Accessory
Be sure to use the adapter
included in the kit
5
Motor cable
1
8-pin cable
Accessory
6
CAN cable
1
3-pin cable
Accessory
7
PC
1
On which Windows XP normally
runs and USB2.0 ports are
supported
Prepare the PC by yourself.
