32 INT6/PPG5/RX0/P16 CAN TRANSCEIVER
33 PPG6/TX0/P17 CAN TRANSCEIVER
34 ADTG1/IC2/P20 Motor driver circuit Hall W-phase
35 ADTG2/IC3/P21 -
36 PWI0/P22 -
37 DTTI/P23 -
38 CKI/P24 -
39 IC0/P25 Motor driver circuit Hall U-phase
40 IC1/P26 Motor driver circuit Hall V-phase
41 P27 SW5
42 PPG0/PG1 -
43 MD2 SW4
44 MD1 GND
45 MD0 GND
46 X0 Q1 4-MHz oscillator
47 X1 Q1 4-MHz oscillator
48 Vss GND
49 PPG4/P37 -
50 INT7/PPG7/P36 -
51
INIT
RESET(SW1)
52 RTO5/P35 Motor driver circuit W-phase Low
53 RTO4/P34 Motor driver circuit W-phase High
54 RTO3/P33 Motor driver circuit V-phase Low
55 RTO2/P32 Motor driver circuit V-phase High
56 RTO1/P31 Motor driver circuit U-phase Low
57 RTO0/P30 Motor driver circuit U-phase High
58 INT0/P40 SW2 SW pressed = L
59 INT1/P41 SW3 SW pressed = L
60 INT2/P42 USB-UART conversion
61 INT3/P43 USB-UART conversion
62 AVRH1 5 V
63 AVRH2 5 V
64 AVcc 5 V
