Page 36

AN07-00180-3E

- 36 -

2.1

Executing in single chip mode

In single chip mode, take the following procedures.

(1) Building a project

(2) Writing the program into the microcontroller

2.1.1

Building a project

Preparation

Extract the following file from the inside of the folder extracted by “1.1.1 Downloading the software”.

¥sample programs¥

bitpot_red_SampleProgram.zip

Select “Start” → “All Programs” → “Softune V6” → “FR Family Softune Workbench” to activate

SOFTUNE.

As shown in “Figure 2-1 Opening a workspace”, select the menu of SOFTUNE, “File” and then “Open

Workspace” to open a workspace.

Figure 2-1 Opening a workspace
