AN07-00180-3E
- 43 -
2.2 Debugging by using Monitor Debugger
To debug by using Monitor Debugger, take the following procedures.
(1) Writing Monitor Debugger into the microcontroller
(2) Activating SOFTUNE and configuring the debug settings
(3) Writing the program into the microcontroller
(4) Loading the target file
(5) Running the debugger
2.2.1 Writing Monitor Debugger into the microcontroller
Preparation
Extract the following file from the inside of the folder extracted by “1.1.1 Downloading the software”.
¥sample programs¥ bitpot_red_SampleProgram_md_set.zip
Select “Start” → “All Programs” → “FUJITSU FLASH MCU Programmer” → “MB91F267NA” to
activate PC Writer.
As shown in “Figure 2-11 Opening the file to write”, to select a file to be written, click the “Open”
button.
Figure 2-11 Opening the file to write
Click this.
