FUJITSU CAN-Motor Board MB91F267N User Manual
Page 34
AN07-00180-3E
- 34 -
Connect the USB cable included in the kit to a USB port on the PC and the USB port on the board. Be
sure to directly connect between them without using a USB hub.
Figure 1-24 Connection between the PC and the board
The power of the board is supplied via USB (USB bus power).
[Note]
If a driver installation dialog is displayed after connecting the board to the PC, USB drivers
may be incorrectly installed.
Install drivers according to the USB driver installation manual.
After SOFTUNE installation,
connect the USB cable.
USB port
Connect a USB port on the PC.
For information about port locations and so forth, refer to the manual of the PC.
