Concerning receive processing, as shown in “Figure 5-15 CAN receive processing”, there is the
canRecvTask function around Line 625 in MAIN.C. First, the receive function canRecvData, which is a
CAN driver API, is invoked by received ID, and then only those with receiveData are processed.
Figure 5-15 CAN receive processing
void canRecvTask(void)
{
(omitted)
/* CAN Receive Data */
ret = canRecvData(1, &canID, &dlc, recvData);
(omitted)
/* CAN Receive Data */
ret = canRecvData(2, &canID, &dlc, recvData);
(omitted)
/* CAN Receive Data */
ret = canRecvData(3, &canID, &dlc, recvData);
(omitted)
}
←ID：0x0101 receive check
←ID：0x0101 receive processing
←ID：0x0102 receive check
←ID：0x0102 receive processing
←ID：0x0103 receive check
←ID：0x0103 receive processing
