AN07-00180-3E

- 48 -

2.2.2

Activating SOFTUNE and configuring the debug settings

Preparation

Set MODE on the board to “RUN” in advance, and then press the Reset button.

Select “Start” → “All Programs” → “Softune V6” → “FR Family Softune Workbench” to activate

SOFTUNE.

As shown in “Figure 2-17 Opening a workspace”, from a menu of SOFTUNE, select “File” → “Open

Workspace” to open a workspace.

Figure 2-17 Opening a workspace
