DM Series Industrial Monitor
Page 96
Figure 4-16: 5V Power Connector Location
4.3.9 12V Power Connector
CN Label: CN7
CN Type: 2-pin header
CN Pinouts: See Table 4-22
CN Location: See Figure 4-17
The 12V power connector is a general-purpose power connector.
Pi
n
Descriptio
n
Pi
n
Descriptio
n
1 +12V 2 GND
Table 4-22: 12V Power Connector Pinouts
