4.4.3 AV-5300 Peripheral Interface Connectors
Table 4-30 shows a list of the peripheral interface connectors on the AV-5300 AD board.
Detailed descriptions of these connectors can be found in Section 4.4.6.
Connector Type Label
Auto-dimming connector 6-pin wafer connector CN16
Debug connector 4-pin wafer connector CN4
External OSD and LED Indication connector 9-pin wafer connector CN3
Inverter interface connector 6-pin wafer connector CN2
LVDS connector 30-pin connector CN8
Power output connectors 2-pin wafer connector CN12, CN13
Power input connectors 3-pin wafer connector CN24. CN25
VGA connector 10-pin box header J1
Table 4-30: AV-5300 Peripheral Interface Connectors
4.4.4 AV-5300 Rear Panel Connectors
Table 4-31 lists the rear panel connectors on the AV-5300 AD board. Detailed
descriptions of these connectors can be found in Section 4.4.18.
Connector Type Label
12V DC power connector DC Power Jack J3
DVI connector 24-pin DVI-D connector J2
VGA connector 15-pin VGA connector J5
Table 4-31: AV-5300 Rear Panel Connectors
