DM Series Industrial Monitor
Page 88
PI
N
DESCRIPTION
PI
N
DESCRIPTION
1
DOWN/AUTO
ADJUST 3
No
Connect
2 Ground
4 No
Connect
Table 4-14: OSD Control Button JP3 Pinouts
PI
N
DESCRIPTION
PI
N
DESCRIPTION
1
LCD ON/OFF
3
No Connect
2 Ground
4 No
Connect
Table 4-15: OSD Control Button JP4 Pinouts
4.2.18 VGA Connector
CN Label:
CN1
CN Type:
HD-D-sub 15 female connector
CN Pinouts:
See Table 4-16 and Figure 4-11
CN Location:
Use the standard HD-D-sub 15-pin VGA connector to connect the monitor to a system.
PIN
DESCRIPTION
PIN
DESCRIPTION
1 Red
9 No
Connect
2 Green
10
Ground
3 Blue
11
No
Connect
4 No
Connect 12
DDC
DAT
5 Ground
13
Horizontal
Synchronization
6 Ground
14
Vertical
Synchronization
7 Ground
15
DDC
Clock
8 Ground
