4.2.8 5V Power Connector
CN Label: CN11, CN12
CN Type: 2-pin header
CN Pinouts: See Table 4-4
CN Location: See Figure 4-3
The 5V power connector is a general-purpose power connector.
Pi
n
Descriptio
n
Pi
n
Descriptio
n
1 +5V 2 GND
Table 4-4: 5V Power Connector Pinouts
Figure 4-3: 5V Power Connector Location
