DM Series Industrial Monitor
Page
79
4.2.10 External OSD and LED Indication Connector
CN Label: CN4
CN Type: 9-pin header
CN Pinouts: See Table 4-6
CN Location: See Figure 4-5
The External OSD and LED Indication connector connects to an external OSD controller.
Pi
n Description
1
LED_ORANG
E
2 +5V
3 LED_GREEN
4
MENU/ENTE
R
5 RIGHT
6 LEFT
7 AUTO
8 LCD ON/OFF
9 GND
Table 4-6: External OSD and LED Indication Connector Pinouts
