DM Series Industrial Monitor
Page
25
1.3.1 Front View
The front of the DM series industrial monitor is a flat panel TFT LCD screen surrounded by
an aluminum frame. A control button panel (OSD), if available, is located either vertically
on the right side of the frame or horizontally along the bottom of the frame with the
following control buttons:
„ LCD On/Off
„ Auto
„ Left
„ Right
„ Menu
The OSD panel also has one power LED.
Figure 1-1 shows a typical monitor front view.
Figure 1-1: Typical Monitor Front View
