Table 4-16: VGA Connector Pinouts
Figure 4-11: VGA Connector Pinout Locations
4.2.19 AV-9350 Onboard Jumper
NOTE:
A jumper is a metal bridge used to close an
electrical circuit. It consists of two or three metal
pins and a small metal clip (often protected by a
plastic cover) that slides over the pins to
connect them. To CLOSE/SHORT a jumper
means connecting the pins of the jumper with
the plastic clip and to OPEN a jumper means
removing the plastic clip from a jumper.
Figure 4-12: Jumpers
The AV-9350 has one onboard jumper (Table 4-3).
