Table 2-11 lists the number of holes each monitor has for mounting to a rack or cabinet.
Model Holes
DM-170 16
DM-150 12
DM-121 8
DM-104 10
Table 2-11: Rack Mounting Clamps
2.6.3 Wall Mounting
Each model of the DM series industrial monitor has four holes located on the rear panel for
mounting the monitor to a wall. Figure 2-13 shows the typical methods for wall
mounting.
Figure 2-13: Typical Wall Mounting
