DM Series Industrial Monitor
Page 110
4.4.5 AV-5300 On-board Jumpers
Table 4-32 lists the on-board jumpers. A detailed description of these jumpers can be
found in Section 4.4.15.
Jumper Type Label
LCD Panel Power Input Select 6-pin header JP4
LCD Panel Voltage Select 6-pin header JP1
Table 4-32: AV-5300 On-board Jumpers
4.4.6 AV-5300 Internal Peripheral Connectors
Internal peripheral connectors on the AV-5300 AD board are only accessible when the
board is outside of the monitor. This section has complete descriptions of all the internal,
peripheral connectors on the AV-5300 AD board.
4.4.7 Auto-Dimming Connector
CN Label: CN16
CN Type: 6-pin wafer connector
CN Pinouts: See Table 4-33
CN Location: See Figure 4-28
The auto-dimming connector connects to an external auto-dimming sensor.
PIN DESCRIPTION
1 +3.3V
2 NC
3 GND
4 SCL
5 NC
6 SDA
