4.3.13 VGA Connector
CN Label:
J2
CN Type:
10-pin header
CN Pinouts:
CN Location:
In addition to the standard DB-15 female VGA connector (J1), a VGA connection can also
be made through the onboard CN2 10-pin header.
Pi
n
Descriptio
n
Pi
n
Descriptio
n
1 RED
2 DDCCLK
3 GREEN
4 DDCDAT
5 BLUE
6 GROUND
7 HSYNC
8 GROUND
9 VSYNC
10
GROUND
Table 4-26: VGA Connector Pinouts
