DM Series Industrial Monitor
Page 32
2.1 Introduction
This chapter describes the general mechanical overview of the DM series monitors
including front and bottom panel variations, available interfaces and overall dimensions.
2.2 Front Panel
The front panel of the DM series industrial monitor is comprised of a TFT LCD in an
aluminum frame with an OSD control panel.
2.2.1 Front Panel Variants
Table 2-1 shows the three front panel variants for the DM series industrial monitor.
Model OSD Control Panel Location
Variant
Number
DM-170, DM-150, DM-121,
DM-104, DM-84
Vertically along the right side
of the aluminum frame
1
DM-190
Horizontally along the bottom
of the aluminum frame
2
DM-65
In line along the bottom
of the rear panel
3
Table 2-1: Front Panel Variants
