3.2.2 Touch Panel Dimensions
shows the touch panel dimensions in millimeters.
Model:
Dimension
Width
Length
Thick
Dimensional
Outline:
330 404.6 2.8
Viewing Area:
306.05
381.3 -
Active Area:
301.05
376.3 -
PanJit
1190503A
Key Area:
300.05
375.3 -
Dimensional
Outline:
365 295.08
2.9
Viewing Area:
342.05
275.45
-
Active Area:
342.05
275.45
-
PanJit
1171505A
Key Area:
338.0
271.4
-
Dimensional
Outline:
257.5 333.6 2.9
Viewing Area:
232.1
308.2
-
PanJit
1150508B
Active Area:
228.1
304.1
-
Dimensional
Outline:
204 268 2.1
Viewing Area:
188
250
-
PanJit
1121505B
Active Area:
185
246
-
Dimensional
Outline:
238.8 188.7 2.6
Viewing Area:
219.8
166.8
-
PanJit
1104502A
Active Area:
212.1
159.3
-
Dimensional
Outline:
145.53
188.04
2.1
Viewing Area:
130.75
173.38
-
PanJit
1084403B
Active Area:
127.78
170.38
-
PanJit
1065403C
Dimensional
Outline:
150.00
117.50
2.1
