DM Series Industrial Monitor
Page 86
4.2.15 DC 12V Connector
CN Label:
J2
CN Type:
DC 12V Jack
CN Pinouts:
CN Location:
Use the DC 12V connector to power the monitor.
PI
N
DESCRIPTION
1 GND
2 GND
3 DC
12V
Table 4-10: DC 12V Connector Pinouts
4.2.16 RS232 Serial Connector
CN Label:
J1
CN Type:
D-Sub 9 female connector
CN Pinouts:
See Table 4-11 and Figure 4-10
CN Location:
Use the RS-232 serial connector to connect the touch panel.
PI
N
DESCRIPTION
PI
N
DESCRIPTION
1 DCD
6 DSR
2 RXD
7 RTS
3 TXD
8 CTS
4 DTR
9 RI/Vout
