Configuring IP Addressing
Loopback Interfaces
To display the loopback interfaces configured on the switch in a list of IP
routing entries displayed according to destination IP address, enter the
show
ip route command.
The following example displays the configuration of the default loopback
interface (
lo0) and one user-defined loopback interface (lo2).
ProCurve> show ip route
IP Route Entries
IP Routing : Enabled
Default TTL : 64
ARP Age : 20
Destination Gateway VLAN Type Metric Dist
----------- ---------- ---- ------ ----- ---
10.0.0.0/16 DEFAULT_VLAN 1 connected 1 0
127.0.0.0/8 reject static 0 0
127.0.0.1/32 lo0 connected 1 0
172.16.10.121/32 lo2 static 1 0
172.16.102.0/24 VLAN2 2 connected 1 0
Figure 8-8. Example of show ip route Command Output
8-19
