OMS OMNEO Main Station

Basic operation | en

Bosch Security Systems, LLC

Technical Manual

01-2021 | 03 | F.01U.380.820

Keypad

Character/Mode

MENU Home

screen

Port Status

Overview

Menu

Form

(navigating)

Form

(navigating) +

SHIFT

6/RIGHT

Rotate icon
highlight CW

Move icon
highlight
right

Move to next
field (right)

7/MICSEL

Go to ALARM
menu

8/DOWN

Scroll info
down

Move to next
sibling menu

Move to next
field (down)

9/CWTLK

Go to SETUP
menu

0/SHIFT

Toggle SHIFT
state

*/CLR

Go to keypanel
screen

Go to
keypanel
screen

Move up one
menu level

Exit form
(prompt if
changes)

Exit form
(abort
changes)

#/SEL

Select
highlighted
icon

Initiate edit
on selected
field

Exit form
(save
changes)

Tab. 10.14: Keypad operation when MENU is active

Action / Mode

Home

Port Status

Overview

Menu

Form

(navigating)

Form

(navigating) +

SHIFT

ENC1 (Left Encoder)

Click

Go to keypanel
screen

Go to Link
Status
Overview

Move up
one level

Exit form
(prompt if
changes)

Double-click

Move to info
top

Move up
one level

Exit form
(abort
changes)

Press + Hold

Activate
screensaver

Rotate

Scroll info up /
down

Scroll info
up / down

Move to
next / prev
sibling

Scroll form
up / down

ENC2 (Right Encoder)

Click

Invoke
highlighted
icon

Initiate edit
on selected
field
