136

en | Intercom setup | Party line membership

OMS OMNEO Main Station

01-2021 | 03 | F.01U.380.820

Technical Manual

Bosch Security Systems, LLC

Figure 27.4:

Permanent talker/listener screen

There are four configuration options for this screen.

Assignment

Description

Talker

The party line membership assignment is always talking.

Listener

The party line membership assignment is always listening.

Both

The party line membership assignment is always talking and listening.

None

The party line membership assignment is cleared from the key.

Tab. 27.19: Configuration Options for Permanent Talker/Listener Screen

To

configure a party line membership using the permanent talker/listener view

, do the

following:
1.

Navigate to the

Party Line Membership menu item

.

2.

Press

SEL

.

The Party Line Membership matrix grid displays.

3.

Use the arrow keys to navigate to the

desired port and party line

.

4.

Press

SEL

.

The Talker/Listener View appears.

5.

Use the arrow keys to select

Talker

,

Listener

, or

Both

.

6.

Press

SEL

.

The assignment is made and the Party Line Membership matrix grid appears with the
configured party line membership.

To

clear a party line membership from the talker/listener view

, do the following:

1.

Navigate to the

Party Line Membership menu item

.

2.

Press

SEL

.

The Party Line Membership matrix grid displays with the assignment configured.

3.

Use the arrow keys to navigate to the

desired port and party line

.

4.

Press

SEL

.

The Talker/Listener View appears.

5.

Use the arrow keys to select

None

.

6.

Press

SEL

.

The assignment is removed and the Party Line Membership matrix grid screen appears
with the membership removed.
